Industrial CAT6 RJ45 Jack All Materials Mates With Modular Plug TMZJ014058
Industrial CAT6 RJ45 Jack All Materials Mates With Modular Plug TMZJ014058
Contact Now

Industrial CAT6 RJ45 Jack All Materials Mates With Modular Plug TMZJ014058

Minimum Order Quantity : 1 piece Price : Please contact us to get the latest price
Packaging Details : Tray in Carton Delivery Time : 10 days
Payment Terms : L/C, T/T, Western Union, MoneyGram Supply Ability : 100K pcs/day
Place of Origin: Guangdong of China Brand Name: TM
Certification: UL,Rohs,Reach,ISO9001 Model Number: TMZJ014058

Detail Information
Number Of Positions: 8 Terminals Per Port: 8
LED Option: No Shielded EMI Tabs: No
Voltage Rating: 125 V Current Rating: 1.5 A
Contact Resistance: 30mΩ Insulation Resistance: 500 MΩ MIN @ 500V DC
Dielectric Resistance: 1000V AC RMS 50Hz. 1MIN Durrability: 750 CYCLES MIN
Minimal Order: 1pcs Manner Of Packing: Tray In Carton
Delivery Time: 20 Days Supply Ability: 5KK/year
High Light:

cat6 shielded jack

,

cat6 female jack

Product Description

Industrial Cat6 RJ45 Female connector All materials mates with modular plug Length 24.10 mm TMZJ014058





Product Structure:
1 x 1 Port / Single Port / One Port
Connector Length: 24.10 mm
Connector Width: 10.5 mm
Connector Height: 12.3 mm
Termimal Solder Pin Length: 0 mm
8P8C ( 8 positions 8 contacts )
180°Orientation
Without led, let know the connection status
Without Shield,can be customized as required
We Support Custom service as required



RJ45 Without Transformer (TMZJ014058) Attributes:

Model: TMZJ014058
Place of Origin: Guangdong of China
Certification: UL,Rohs,Reach,ISO9001
Product Type : RJ45 Modular Connector
Jack Type: RJ45
Number of Positions : 8
Terminals per Port: 8
LED Option: No
Shielded EMI Tabs: No
Voltage rating: 125 V
Current rating: 1.5 A
Contact resistance: 30mΩ
Insulation resistance: 500 MΩ MIN @ 500V DC
Dielectric resistance: 1000V AC RMS 50Hz. 1MIN
Durrability: 750 CYCLES MIN
Minimal Order: 1pcs
Manner of packing : Tray
Delivery Time: 20 Days
Supply Ability: 5KK/year



RJ45 Female Connector (TMZJ014058) Mechnical Drawing:

 Industrial CAT6 RJ45 Jack All Materials Mates With Modular Plug TMZJ014058 0
