Product Description
Pure Copper RJ45 Extension Cable with Ear Fixed with Screw Hole RJ45 Network male to female Extension Cable TMCABLE060123
RJ45 cable for Ethernet connection
The Ethernet cable has RJ45 connectors on both ends. For this reason, Ethernet cables are sometimes designated as RJ45 cables. These cables are commonly used to connect computers to Ethernet networks. An RJ45 connector is similar to a six-pin RJ11 connector, but the 45 is slightly wider. Since each connector has eight pins, an RJ45 Ethernet cable will have eight wires of different colors. RJ45 cables can be routed according to two different schemes, T-568 A or B, depending on the devices to be connected in the network. Crossover cables have a different wiring scheme at each end to support computer-to-computer connections.
Materials:
CONNECTOR P1(RJ45 JACK):
Housing:PBT,BLACK,UL94V-0 ( RoHS )
Holder:LCP,BLACK,UL94V-0 ( RoHS )
Contact material:OD=0.2*0.35mm flat needle nickel plating, tin plating, contact area gold plating( RoHS )
Gold plating:Fu”(Optional)
Shielding Shell: 0.2 mm thickness Copper alloy with Nickel Plating over all
CONNECTOR P2(US PLUG):
Housing:PC,UL94V-0 ( RoHS )
Contact material:T=0.3mm Copper alloy nickel plating, contact area gold plating( RoHS )
Gold plating:Fu”(Optional)
Shielding Shell:Copper alloy with Nickel Plating over all
CABLE: FTP 24AWG*4P(7/0.20BC)+AEB OD5.8mm BLACK PVC( RoHS )
MOLDING: PVC Black UL94V-0(RoHS)
Shielding: With
All materials mates with modulat plug conforming to FCC part 68. subpart F.
Product Structure:
RJ45 CABLE
One plug to one jack Cable
CABLE Length: 300 mm
RJ45 Connector Lock hole spacing: 28.27 mm
RJ45 Connector Lock hole size: M3
8P8C ( 8 positions 8 contacts )
180°Orientation
Without LED, let know the connection status
With Shield,can be customized as required
We Support Custom service as required
RJ45 Connector Cable(TMCABLE060123) Attributes:
| Model: |
|
| Place of Origin: |
Guangdong of China |
| Certification: |
UL,Rohs,Reach,ISO9001 |
| Product Type : |
RJ45 Connector Cable |
| Jack Type: |
RJ45 |
| Number of Positions : |
8 |
| Terminals per Port: |
8 |
| LED Option: |
No |
| Shielded: |
Yes |
| Cable Color: |
Black |
| Durrability: |
750 CYCLES MIN |
| Minimal Order: |
500 pcs |
| Package: |
1pcs/bag |
| Carton size: |
/ |
| Delivery Time: |
20 Days |
| Payment Terms: |
|
| Supply Ability: |
300K/year |
RJ45 Connector Cable ( TMCABLE060123) Mechnical Drawing:
