Power Over Ethernet RJ45 Single Port / Poe Rj45 Jack For Networking Switch TM114B05DE1

Name: Power Over Ethernet RJ45 Single Port / Poe Rj45 Jack For Networking Switch TM114B05DE1
Brand: TM
SKU: TM114B05DE1
Price: 1.00 USD
Availability: InStock
Rating: 4.6 (200 reviews)

Minimum Order Quantity :	500 piece	Price :	Supportive
Packaging Details :	Tray in Carton	Delivery Time :	3 work days
Payment Terms :	T/T, Western Union, ,Paypal	Supply Ability :	100kpcs /day

Place of Origin:	Guangdong of China	Brand Name:	TM
Certification:	UL,Rohs,Reach,ISO9001	Model Number:	TM114B05DE1

Detail Information
CONTACT MATING AREA PLATING:	GOLD 6U'' PLATING	CONNECTOR TYPE:	BLACK
LED OPTION:	LEFT GREEN,RIGHT YELLOW	NUMBER OF PORTS:	1X3
NUMBER OF CONTACTS:	10	GROUNDING OPTIONS:	Panel Ground And PCB Ground
SHIELD PLATING MATERIAL:	NICKEL	SHIELD EMI TABS:	YES
SHIELD:	YES	ROHS COMPLIANT:	YES
PANEL STOP:	YES	PCB MOUNT ANGLE:	SIDE ENTRY
PACKAGE:	DIP	CONNECTOR & CONTACT TERMINAATES TO:	Printed Circuit Board
LATCH ORIENTATION:	LATCH DOWN
High Light:	rj45 modular socket , shielded rj45 jack

Product Description

good quality RJ45 Power Over Ethernet (PoE+) RJ45 Jack With Leds 1000Base for Networking Switch TM114B05DE1

RJ45 Without Transformer (TM114B05DE1) Attributes:

Model Number	TM114B05DE1
LENGTH	21.3mm
HOUSING MATERIAL	PBT UL94V-0
CONTACT MATING AREA PLATING	GOLD 6U'' PLATING
CONNECTOR TYPE	RJ45
CONNECTOR MATERIAL COLOR	BLACK
LED OPTION	LEFT GREEN,RIGHT YELLOW
NUMBER OF PORTS	1X3
NUMBER OF CONTACTS	8
GROUNDING OPTIONS	Panel Ground and PCB Ground
SHIELD PLATING MATERIAL	NICKEL
SHIELD EMI TABS	YES
SHIELD	YES
ROHS COMPLIANT	YES
PANEL STOP	YES
PCB MOUNT ANGLE	SIDE ENTRY
PACKAGE	DIP
CONNECTOR & CONTACT TERMINAATES TO	Printed Circuit Board
LATCH ORIENTATION	LATCH DOWN

RJ45 Female Connector (TM114B05DE1) Applications:

10/100M net card,PCMCIA net card,USB Hub,network switch,router,fiber optic transceivers,optical transceiver,IP phone,internet set-top box,internet camera,net bridge,computer,telecommunication,MODEM,
HomePNA,DSL／ADSL and so on.

RJ45 Female Connector (TM114B05DE1) Mechnical Drawing:

Power Over Ethernet RJ45 Single Port / Poe Rj45 Jack For Networking Switch TM114B05DE1 0
