USB 3.0 Type A IP68 RJ45 Waterproof Coupler Female To Female

Product Description

USB 3.0 Type A IP68 RJ45 Waterproof Coupler Female To Female

USB 3.0 Type A IP68 Waterproof Coupler Adapter-Panel Mount Female to Female

USB 3.0 AF/AF Coupler Female To Female Transfer For USB 3.0 Cable Waterproof Dustproof Adapter Industrial Grade

The excellent waterproof ability of the USB 3.0 AF/AF Coupler can be applied to any outdoor situation, rain and snow. It is also protected by a waterproof cap when not in use to prevent moisture from entering the equipment.

Materials:
Housing : ABS,UL94V-0 ( RoHS )
Contact Finish: T=0.30 mm GOLD PLATING 6U" OVER NICKEL IN CONTACT TIN PLATING OVER NICKEL IN SOLDER AREA.( RoHS )
Shielding Shell: No shield.
All materials mates with modulat plug conforming to FCC part 68. subpart F.

Product Structure:
USB 3.0 AF/AF Coupler
One to one Port
Connector Length: 33 mm
Operating Temperature:-20°C~+75°C
Current Rating:1.5A
Voltage Rating:125V AC
Withstand Voltage:500V AC
Insulation Resistance:500MΩ
Contact Resistance:30 MΩ
Service life:5000 cycle Min
Without led, let know the connection status
Without Shield,can be customized as required
We Support Custom service as required


USB 3.0 AF/AF Coupler (TMZJT020064) Attributes:,


USB 3.0 AF/AF Coupler (TMZJT020064) Mechnical Drawing:


Do RJ45 couplers affect speed?
No, ethernet couplers will not reduce speed. Once the connection is established, the speed remains the same. The problem causes packet loss, so throughput may decrease due to resends, but speed remains the same.
