RJ45 Jack Waterproof Ethernet Cable Male To Female With Dust Cap

Product Description

RJ45 Jack Waterproof Ethernet Cable Male To Female With Dust Cap

Ethernet Waterproof Cable Male to Female With Dust Cap For Outdoors Rain Panel Mount

Ethernet Waterproof Cable Male to Female With Dust Cap For Outdoors Rain Panel Mount

The length of the waterproof net cable can be customized. One end is the RJ45 PLUG connector and the other end is the RJ45 female connector. The RJ45 female connector can be waterproof. It is installed on the panel and has a waterproof cap. When not in use, it can also prevent water from entering the equipment.

An Ethernet coupler, also known as an RJ45 coupler, is a plastic or metal connector that is open at both ends, usually a female port. These miniature rectangular couplers are designed to connect two Ethernet cables to connect different devices. In layman's terms, an Ethernet coupler is like a knot.
When you plug an Ethernet cable into an Ethernet coupler, the wires in the coupler make contact with the wires in the cable, creating a connection.

Ethernet Waterproof Cable (TMCABLE060246)Attributes:


Ethernet Waterproof Cable(TMCABLE060246)Materials:
Housing : ABS,UL94V-0 ( RoHS )
Contact Finish: T=0.30 mm GOLD PLATING 6U" OVER NICKEL IN CONTACT TIN PLATING OVER NICKEL IN SOLDER AREA.( RoHS )
All materials mates with modulat plug conforming to FCC part 68. subpart F.
Shielding Shell: Stainless Steel.
Ethernet Waterproof Cable (TMCABLE060246)Product Structure:
RJ45 F/M Network Cable
PLUG :US PLUG 8P8C W/0 SHIELD
CONN: RJ45 JACK 8P8C
CABLE: CAT5E UTP 24AWG*4P BLACK OD5. 5mm
8P8C ( 8 positions 8 contacts )
180°Orientation
Without led, let know the connection status
With Shield,can be customized as required
We Support Custom service as required

Ethernet Waterproof Cable (TMCABLE060246)Mechnical Drawing:
