8P8C Female To Female Waterproof RJ45 Network Adapter For Cable Extension

Contact Now

8P8C Female To Female Waterproof RJ45 Network Adapter For Cable Extension

Minimum Order Quantity :	500	Price :	Supportive
Packaging Details :	Vacuum package , ESD package,Carton package	Delivery Time :	20days
Payment Terms :	T/T, Western Union,Paypal	Supply Ability :	100000 Piece/Pieces per Month

Place of Origin:	Guangdong, China (Mainland)	Brand Name:	TM
Certification:	CE/RoHS/ISO9001	Model Number:	OEM

Detail Information
Supplier Type:	Manufacturer	Color:	Customize
MOQ:	500	ODM:	YES
OEM:	YES
High Light:	Waterproof RJ45 Network Adapter , Female To Female RJ45 Network Adapter , 8P8C RJ45 Network Coupler

Product Description

RJ45 Network Adapter Female To Female Waterproof Dustproof Coupler Industrial Grade For Cable Extension

RJ45 Network Adapter Female (TMPMWRJ0001) Attributes:

Model:	TMPMWRJ0001
Place of Origin:	Guangdong of China
Certification:	UL,Rohs,Reach,ISO9001
Product Type :	RJ45 Modular Connector
Jack Type:	RJ45
Number of Positions :	8
Terminals per Port:	8
LED Option:	No
Shielded EMI Tabs:	No
Voltage rating:	125 V
Current rating:	1.5 A
Contact resistance:	40mΩ
Insulation resistance:	500 MΩ MIN @ 500V DC
Dielectric resistance:	1000V AC RMS 50Hz. 1MIN
Durrability:	750 CYCLES MIN
Minimal Order:	1pcs
Manner of packing :	50pcs/tray,500pcs/case
Delivery Time:	20 Days
Supply Ability:	5KK/year

RJ45 Network Adapter Female (TMPMWRJ0001) Mechnical Drawing:

8P8C Female To Female Waterproof RJ45 Network Adapter For Cable Extension 0

Materials:

Housing : ABS,UL94V-0 ( RoHS )
Contact Finish: T=.35 mm Phosphor Bronze gold plating(Fu” ~50u”Optional) over nickel in contact.
Shielding Shell: Stainless Steel
All materials mates with modulat plug conforming to FCC part 68. subpart F.

Operating Temperature:-20°C~+75X

Current Rating:1.5A

Voltage Rating:125V AC

Withstand Voltage:1000V AC

Insulation Resistance:1000MQ

Contact Resistance:30mQ

Service life:750 cycle Min

Product Structure:
RJ45 Modular Jack
1 x 1 Port / Single Port / One Port
RJ45 Connector Width: 28.71 mm
RJ45 Connector Height: 43.20 mm
8P8C ( 8 positions 8 contacts )
180°Orientation
Without LED, let know the connection status
With Shield,can be customized as required
We Support Custom service as required
