1x1 Single Port SMT Type Low Profile RJ45 PCB Jack
1x1 Single Port SMT Type Low Profile RJ45 PCB Jack 1x1 Single Port SMT Type Low Profile RJ45 PCB Jack 1x1 Single Port SMT Type Low Profile RJ45 PCB Jack 1x1 Single Port SMT Type Low Profile RJ45 PCB Jack 1x1 Single Port SMT Type Low Profile RJ45 PCB Jack
Contact Now

1x1 Single Port SMT Type Low Profile RJ45 PCB Jack

Minimum Order Quantity : 500/1000/2000 pcs Price : Supportive
Packaging Details : 180pcs/tray,1440pcs/carton Delivery Time : 20 Days
Payment Terms : T/T, Western Union,Paypal Supply Ability : 500K/year
Place of Origin: Guangdong of China Brand Name: TM
Certification: UL,Rohs,Reach,ISO9001 Model Number: TM56S011SXX41

Detail Information
Number Of Positions: 10 Terminals Per Port: 10
Product Type: RJ45 Modular Connector Jack Type: RJ45
Shielded EMI Tabs: No Voltage Rating: 125 V
Current Rating: 1.5 A Contact Resistance: 30mΩ
Insulation Resistance: 500 MΩ MIN @ 500V DC Dielectric Resistance: 1000V AC RMS 50Hz. 1MIN
High Light:

Low Profile RJ45 PCB Jack

,

1x1 RJ45 PCB Jack

,

10P10C SMT RJ45 Jack

Product Description

General RJ45 PCB Jack 1x1 Single Port SMT Type low Profile rj45



Materials:

Housing : PA9T/FR52,UL94V-0 ( RoHS )

Contact Finish: T=0.35 mm GOLD PLATING FU" OVER NICKEL IN CONTACT TIN PLATING OVER NICKEL IN SOLDER AREA.( RoHS )

Shielding Shell: NO.

All materials mates with modulat plug conforming to FCC part 68. subpart F.



Product Structure:

1 x 1 Port / Single Port / SMT Port

Connector Length: 18.10 mm

Connector Width: 15.00 mm

Connector Height: 11.50 mm

Termimal Solder Pin Length: 2.50 mm

10P10C ( 10 positions 10 contacts )

90°Orientation

Without LED, let know the connection status

Without Shield,can be customized as required

We Support Custom service as required



RJ45 Without Transformer (TM56S011SXX41) Attributes:

Model: TM56S011SXX41
Place of Origin: Guangdong of China
Certification: UL,Rohs,Reach,ISO9001
Product Type : RJ45 Modular Connector
Jack Type: RJ45
Number of Positions : 10
Terminals per Port: 10
LED Option: NO
Shielded EMI Tabs: No
Voltage rating: 125 V
Current rating: 1.5 A
Contact resistance: 30mΩ
Insulation resistance: 500 MΩ MIN @ 500V DC
Dielectric resistance: 1000V AC RMS 50Hz. 1MIN
Durrability: 750 CYCLES MIN
Minimal Order: 1pcs
Package: 180pcs/tray,1440pcs/carton
Carton size: 35*35*40cm
Delivery Time: 20 Days
Supply Ability: 5KK/year



RJ45 Female Connector (TM56S011SXX41) Mechnical Drawing:
