Home ProductsRJ45 Cable CouplerISO9001 RJ45 Male To Female Network Cable 125V 1.5A With ABS Housing
ISO9001 RJ45 Male To Female Network Cable 125V 1.5A With ABS Housing
ISO9001 RJ45 Male To Female Network Cable 125V 1.5A With ABS Housing ISO9001 RJ45 Male To Female Network Cable 125V 1.5A With ABS Housing ISO9001 RJ45 Male To Female Network Cable 125V 1.5A With ABS Housing ISO9001 RJ45 Male To Female Network Cable 125V 1.5A With ABS Housing ISO9001 RJ45 Male To Female Network Cable 125V 1.5A With ABS Housing
Contact Now

ISO9001 RJ45 Male To Female Network Cable 125V 1.5A With ABS Housing

Minimum Order Quantity : 100pcs Price : Supportive
Packaging Details : 50pcs/tray Delivery Time : 20 Days
Supply Ability : 500K/year
Place of Origin: Guangdong of China Brand Name: TM
Certification: UL,Rohs,Reach,ISO9001 Model Number: TMCABLE060245

Detail Information
Product Type : RJ45 F/M Network Cable Jack Type: RJ45
LED Option: No Shielded EMI Tabs: No
Voltage Rating: 125 V Current Rating: 1.5 A
Contact Resistance: 30mΩ Durrability: 750 CYCLES MIN
High Light:

ISO9001 Male To Female Network Cable

,

125V Male To Female Network Cable

,

ABS Housing RJ45 Network Cable

Product Description

RJ45 Male to Female Network Cable With Waterproof Sets For outdoors



RJ45 Male to Female Network Cable (TMCABLE060245)Attributes:

Model: TMCABLE060245
Place of Origin: Guangdong of China
Certification: UL,Rohs,Reach,ISO9001
Product Type : RJ45 F/M Network Cable
Jack Type: RJ45
Number of Positions : 8
Terminals per Port: 8
LED Option: No
Shielded EMI Tabs: No
Voltage rating: 125 V
Current rating: 1.5 A
Contact resistance: 30mΩ
Insulation resistance: 500 MΩ MIN @ 500V DC
Dielectric resistance: 1000V AC RMS 50Hz. 1MIN
Durrability: 750 CYCLES MIN
Minimal Order: 100pcs
Manner of packing : 50pcs/tray,500pcs/case
Delivery Time: 20 Days
Supply Ability: 5KK/year

RJ45 Male to Female Network Cable With Waterproof Sets For outdoors

RJ45 Male to Female Network Cable (TMCABLE060245)Materials:

Housing : ABS,UL94V-0 ( RoHS )
Contact Finish: T=0.30 mm GOLD PLATING 6U" OVER NICKEL IN CONTACT TIN PLATING OVER NICKEL IN SOLDER AREA.( RoHS )
All materials mates with modulat plug conforming to FCC part 68. subpart F.

Shielding Shell: Stainless Steel.


RJ45 Male to Female Network Cable (TMCABLE060245)Product Structure:
RJ45 Modular Jack
Connector Length: 27.6 mm
Connector Width: 14.40 mm
Connector Height: 16.00 mm
8P8C ( 8 positions 8 contacts )
180°Orientation
Without led, let know the connection status
With Shield,can be customized as required
We Support Custom service as required



RJ45 Male to Female Network Cable (TMCABLE060245)Mechnical Drawing:

ISO9001 RJ45 Male To Female Network Cable 125V 1.5A With ABS Housing 1
