Female 6P6C RJ11 Inline Coupler telephone adapter modular jack
Female 6P6C RJ11 Inline Coupler telephone adapter modular jack Female 6P6C RJ11 Inline Coupler telephone adapter modular jack Female 6P6C RJ11 Inline Coupler telephone adapter modular jack
Contact Now

Female 6P6C RJ11 Inline Coupler telephone adapter modular jack

Minimum Order Quantity : 500/1000/2000 pcs Price : Supportive
Packaging Details : 50pcs/tray,500pcs/case 20 Days Delivery Time : 20 Days
Payment Terms : T/T, Western Union,Paypal Supply Ability : 500K/year
Place of Origin: Guangdong of China Brand Name: TM
Certification: UL,Rohs,Reach,ISO9001 Model Number: TMZT8511SK001107A41013

Detail Information
Jack Type: RJ11 Number Of Positions: 6
Terminals Per Port: 6 Shielded EMI Tabs: No
Voltage Rating: 125 V Current Rating: 1.5 A
Contact Resistance: 30mΩ Insulation Resistance: 500 MΩ MIN @ 500V DC
High Light:

6P6C RJ11 Inline Coupler

,

Female RJ11 Inline Coupler

,

Rj11 6P6C Connector

Product Description

Female 6P6C RJ11 Inline Coupler Telephone Adapter Modular Jack



female rj11 6P6C connector to 6P6C rj11 telephone adapter modular jack TMZT8511SK001107A41013



RJ11 Telephone Adapter (TMZT8511SK001107A41013)Materials:

Housing : PBT,UL94V-0 ( RoHS )

Contact Finish: OD=0.46mm GOLD PLATING FU" OVER NICKEL.( RoHS )

Shielding Shell: No shield.

All materials mates with modulat plug conforming to FCC part 68. subpart F.



RJ11 Telephone Adapter (TMZT8511SK001107A41013) Attributes:

Model: TMZT8511SK001107A41013
Place of Origin: Guangdong of China
Certification: UL,Rohs,Reach,ISO9001
Product Type : RJ11 Modular Connector
Jack Type: RJ11
Number of Positions : 6
Terminals per Port: 6
LED Option: No
Shielded EMI Tabs: No
Voltage rating: 125 V
Current rating: 1.5 A
Contact resistance: 30mΩ
Insulation resistance: 500 MΩ MIN @ 500V DC
Dielectric resistance: 1000V AC RMS 50Hz. 1MIN
Durrability: 750 CYCLES MIN
Minimal Order: 1pcs
Manner of packing : 50pcs/tray,500pcs/case
Delivery Time: 20 Days
Supply Ability: 5KK/year



RJ11 Telephone Adapter (TMZT8511SK001107A41013) Mechnical Drawing:



Female 6P6C RJ11 Inline Coupler telephone adapter modular jack 0
