90 Degree RJ45 Panel Mount Connector TMZJT020011 Modular Connector
90 Degree RJ45 Panel Mount Connector TMZJT020011 Modular Connector
Contact Now

90 Degree RJ45 Panel Mount Connector TMZJT020011 Modular Connector

Minimum Order Quantity : 500/1000/2000 pcs Price : Supportive
Packaging Details : 100pcs/bag Delivery Time : 20 Days
Payment Terms : T/T, Western Union,Paypal Supply Ability : 500K/year
Place of Origin: Guangdong of China Brand Name: TM
Certification: UL,Rohs,Reach,ISO9001 Model Number: TMZJT020011

Detail Information
Product Type: HDMI Modular Connector Jack Type: HDMI
Number Of Positions: 19 Terminals Per Port: 19
LED Option: No Shielded EMI Tabs: No
Voltage Rating: 40 V Max Current Rating: 0.5 A Max
Contact Resistance: 10mΩ Insulation Resistance: 100 MΩ MIN
Dielectric Resistance: 500V AC RMS 50Hz. 1MIN Durrability：: 750 CYCLES MIN
High Light:

90 Degree RJ45 Panel Mount Connector

,

TMZJT020011 Panel Mount Ethernet Coupler

,

TMZJT020011 HDMI Modular Connector

Product Description

90 Degree RJ45 Panel Mount Connector TMZJT020011 Modular Connector



90 Degree RJ45 Ethernet Connector Adapter / Ethernet Adapter Female To Female



RJ45 90 degree with panel HDMI ,Female to Female straight extension adapter



Materials:
CONNECTOR :
Housing:PBT,BLACK,UL94V-0
Contact material:flat needle nickel plating, tin plating, contact area gold plating( RoHS )
Shielding Shell: Copper alloy with Nickel Plating over all
PCB: FR4 UL94V-0 ( RoHS )
Shell: PVC Black UL94V-0(RoHS)
All materials mates with modulat plug conforming to FCC part 68. subpart F.


Product Structure:
HDMI Modular Jack
One to one Port
Connector Length: 29 mm
Connector Width: 26 mm
Connector Height: 33 mm
Connector Lock hole spacing: 19*24 mm
19P19C ( 19 positions 19 contacts )
180°Orientation
Without LED, let know the connection status
With Shield,can be customized as required
We Support Custom service as required



HDMI Without Transformer (TMZJT020011) Attributes:

Model: TMZJT020011
Place of Origin: Guangdong of China
Certification: UL,Rohs,Reach,ISO9001
Product Type : HDMI Modular Connector
Jack Type: HDMI
Number of Positions : 19
Terminals per Port: 19
LED Option: No
Shielded EMI Tabs: No
Voltage rating: 40 V max
Current rating: 0.5 A max
Contact resistance: 10mΩ
Insulation resistance: 100 MΩ MIN
Dielectric resistance: 500V AC RMS 50Hz. 1MIN
Durrability: 750 CYCLES MIN
Minimal Order: 2000 pcs
Package: 1pcs/bag
Carton size: /
Delivery Time: 20 Days
Payment Terms: T/T, Western Union,Paypal
Supply Ability: 500K/year



HDMI Female Connector ( TMZJT020011) Mechnical Drawing:

90 Degree RJ45 Panel Mount Connector TMZJT020011 Modular Connector 0









Tag:

rj45 female to female adapter

rj45 90 degree adapter

double female ethernet adapter
